Bracke fixed coaxial attenuators with 2.92 mm interfaces are designed to provide controlled signal-level reduction in RF and microwave signal paths. The product family includes versions rated at 2 W, with upper frequency limits of 26.5 GHz or 40 GHz.
Different fixed attenuation values are available depending on the model. This allows the attenuator to be selected according to the required signal level and the operating frequency range of the measurement or system environment.
Advantages
- Two frequency classes: Versions up to 26.5 GHz or 40 GHz for different RF and microwave applications.
- 2 W power rating: Suitable for signal-level adjustment in measurement chains, test setups and low-power RF systems.
- Fixed attenuation values: Defined and repeatable signal-level reduction according to the selected version.
- 2.92 mm interface: Suitable for compact coaxial connections in broadband microwave measurement setups.
- Broad application coverage: Can be used in development, characterisation, production testing and general RF measurement systems.
Key features
- Product type: Fixed coaxial RF attenuator
- Connector type: 2.92 mm
- Power rating: 2 W
- Frequency class 1: Up to 26.5 GHz
- Frequency class 2: Up to 40 GHz
- Attenuation: Fixed value depending on the selected model
- Manufacturer: Bracke Manufacturing
Typical applications
- Defined signal-level reduction in RF and microwave signal paths
- Protection of sensitive measurement instrument inputs against excessive signal levels
- Signal-level adjustment in measurement, test and characterisation setups
- Integration into laboratory and production test systems
- Test setups for RF components, assemblies and systems
- Telecommunications, research and development applications
Additional information
The selection between the 26.5 GHz and 40 GHz versions depends on the operating frequency range of the measurement system and the required fixed attenuation. EMCO supports the selection of a suitable version and its technical positioning within the complete RF or microwave measurement chain.
Comparison of Product Families
Model comparison – BM10059 series up to 26.5 GHz
| Reference | Attenuation | Attenuation accuracy | Frequency range | Power rating | Max. VSWR |
|---|---|---|---|---|---|
| BM10059.1 | 1 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.2 | 2 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.3 | 3 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.4 | 4 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.5 | 5 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.6 | 6 dB | ±0.5 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.7 | 7 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.8 | 8 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.9 | 9 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.10 | 10 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.12 | 12 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.15 | 15 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.20 | 20 dB | ±0.6 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
| BM10059.30 | 30 dB | ±0.8 dB | DC to 26.5 GHz | 2 W | 1.40:1 |
Model comparison – BM10060 series up to 40 GHz
| Reference | Attenuation | Attenuation accuracy | Frequency range | Power rating | Max. VSWR |
|---|---|---|---|---|---|
| BM10060.1 | 1 dB | ±0.6 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.2 | 2 dB | ±0.6 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.3 | 3 dB | ±0.8 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.6 | 6 dB | ±0.8 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.10 | 10 dB | ±1.0 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.20 | 20 dB | ±0.6 dB | DC to 40 GHz | 2 W | 1.30:1 |
| BM10060.30 | 30 dB | ±1.0 dB | DC to 40 GHz | 2 W | 1.40:1 |
